High-Speed Tablet Press: Functionality and Operation

A high-speed tablet press typically has a box-like structure, consisting of four vertical columns connected by bolts, forming the upper and lower halves. Both halves and the columns are constructed using welding. The punches are mounted on the platen, which rotates driven by the main shaft.

The straight alignment of the punches is determined by the upper and lower guide rails. To control tablet thickness, a weight adjustment mechanism allows for altering the position of the lower punch, thereby adjusting the gap between the upper and lower punches.

At the heart of the high-speed press, the main shaft powers the rotating platen with embedded punches. These punches move within the confines of the guiding rails, applying pressure in conjunction with pre压轮 and main press wheel assemblies on both sides of the shaft. Each assembly consists of a pre-pressure roller and a main roller, successively exerting force on the punches as they reach their respective positions, facilitating the formation of compressed tablets.

By optimizing the design of each pressure application, the high-speed tablet press significantly enhances production efficiency compared to traditional systems.

Stay informed about various types of presses, including soft salt tablet press, confectionery tablet press, herbal powder press, effervescent tablet press, chicken bouillon cube press, and health supplement presses, by following our industry insights for the latest developments.

Translation:

A high-speed tablet press typically adopts a box construction, with vertical columns linked by bolts, and a combination of welded upper and lower bodies. The punches rest on a platen attached to the main shaft, which rotates to drive the pressing action. Punch positioning is regulated via guide rails and an adjustable mechanism that manages thickness by modifying the distance between the upper and lower punches.

Central to its operation, the press uses a system where the main shaft powers a platen with rotating punches. These punches are guided by side-mounted pre-pressure and main pressure rollers. By efficiently coordinating the force from these rollers, the high-speed press increases output significantly.

Stay tuned for more on tablet presses like soft salt, candy, herbal, effervescent, chicken bouillon, and health supplements – always staying ahead with our industry updates.
